* Product images and drawings are indicative; final dimensions per engineering drawing. Custom configurations available.
USB 2.0 Feedthrough
USB 2.0 Feedthrough Model: USB2.0USB 2.0 vacuum feedthrough, male / female Type A, for data transmission into vacuum chambers.
Specifications
| Voltage Rating | 30 V DC |
|---|---|
| Max Current | 1 A |
| Vacuum Leak Rate | UHV < 1×10⁻¹⁰ mbar·l/s |
| Flange | CF / KF |
| Interface | USB 2.0 Type A (Male / Female) |
Technical Overview
Multipin feedthroughs carry multiple signal, power and data lines through a single vacuum port, with pins sealed into a ceramic or glass insulator. MIL-Spec MS, USB and SUB-D styles keep contact integrity while preserving UHV hermeticity.
Typical Applications
- Mass spectrometers and surface-analysis instruments
- Vacuum gauges and process instrumentation
- Semiconductor process chambers
- Thin-film deposition and coating systems
